10K510618 Push-in fittings Norgren
10K510618 Push-in fittings Norgren
$20.00
10K510618 Push-in fittings Norgren
General Information
Medium Compressed air
Operating Temperature -20 … 80 °C, -4 … 176 °F
Operating Pressure 0 … 10 bar, 0 … 145 psi
Application General industrial automation
External thread G1/8
O/D Tube 6 mm
External Hex 12 mm
Shape Elbow
Materials – Body Nickel plated brass
Materials – Seals NBR
Dimensions – Height 16.2 mm
Dimensions – Length 31.5 mm
Dimensions – Width 34 mm
Weight 0.04 kg
HONGKONG XIEYUAN TECH CO., LIMITED ava.wong@hkxytech.com Mob/WhatsApp: 86-15602323637
10K510618 Push-in fittings Norgren
- General Information
Medium Compressed air
Operating Temperature -20 … 80 °C, -4 … 176 °F
Operating Pressure 0 … 10 bar, 0 … 145 psi
Application General industrial automation
External thread G1/8
O/D Tube 6 mm
External Hex 12 mm
Shape Elbow
Materials – Body Nickel plated brass
Materials – Seals NBR
Dimensions – Height 16.2 mm
Dimensions – Length 31.5 mm
Dimensions – Width 34 mm
Weight 0.04 kg
Series Pneufit 10
Brand Norgren
- Advantages:
Compact units featuring retained collets and positive tube anchorage
Silicone free O-ring seals
Easy tube insertion for rapid assembly
For quick and simple assembly of pneumatic circuits
Wide range of types available
HONGKONG XIEYUAN TECH CO., LIMITED
ava.wong@hkxytech.com
Mob/WhatsApp: 86-15602323637
